Tungsten Steel CNC Router Burrs End Milling Engraving Bits Drilling Hole Tool

Basic Info

Model NO.	corner raduis end mill
Coating	Coating, Tisin
Tooth Form	Spiral Tooth
Tooth Space	Standard
Structure	Integral
Material	Carbide
Type	Milling Cutter
Application	Metal
Process Usage	Metal-Cutting CNC Machine Tools
Movement Method	Contour Control
Control Method	Closed-Loop Control
Numerical Control	CNC/Mnc
Performance Classification	High-End CNC Machine Tools
Certification	ISO 9001
Condition	New
Grain Size	0.7um
Helix Angle	35 Degree
HRC	45
Bending Strength	>=3800
Usage	General Purpose/High Speed Cutting
Finish Surface	Plain Surface, The Side, Socket
Suitable for	Copper, Cast Iron, Carbon Steel, Mould Steel
Free Service	OEM
Keywords	Tungsten Steel CNC Router Burrs End Milling Engrav
Transport Package	1PC in a Plastic Tube, 10PCS a Group
Specification	SGS
Trademark	Hiboo
Origin	Changzhou Jiangsu China
HS Code	8207709000
Production Capacity	50000PCS/Month

Product Description

Tungsten Steel CNC Router Burrs End Milling Engraving Bits Drilling Hole Tool

1. HRC45 Micro grain carbide rod

HRC45	HRC50	HRC60	HRC65
YG10X	YG10.2 &WF25(Taiwan)	K44 & K40	Sandvik H10F
Grain Size:0.7um Co:10 % Flexural strength:3320N/mm2	Grain Size:0.6um Co:10 % Flexural strength:4000N/mm2	Grain Size:0.5um Co:12 % Flexural strength:4300N/mm2	Grain Size:0.4um Co:12.5 % Flexural strength:4300N/mm2

2. Made by world latest 5-AXIS CNC tools grinder, promise the quality and precision of cutter.

3. Super TiSiN Coating reduce the coeffiction of friction, and improve the tools life much.

	AlTiN	TiAIN	TiSiN	Nano
Hardness(HV)	3200	2800	3600	42(GPA)
Thickness(UM)	2.5-3	2.5-3	3	3
Oxidation Temp(°)	900	800	1000	1200
Friction Coeffient	0.3	0.3	0.45	0.4
Color	Black	Violet	Copper	Blue

4. Each end mill is inspected by Zoller measuring and inspected machine.

5. We accept the specification as your requirement.

6. Work Piece: Suitable for processing steel, stainless steel, nickel alloy, Titanium alloy, cast iron,
Plastic and other materials' hardness below HRC55

order number	cutting	Flute	Shank	Corner	A.0.L
	d	l	D	R Corner	L
1×3×4D×R0.2×50L×4F	1	3	4	R0.2	50
1×3×4D×R0.3×50L×4F	1	3	4	R0.3	50
1.5×3×4D×R0.2×50L×4F	1.5	4	4	R0.2	50
1.5×3×4D×R0.3×50L×4F	1.5	4	4	R0.3	50
2×6×4D×R0.2×50L×4F	2	6	4	R0.2	50
2×6×4D×R0.3×50L×4F	2	6	4	R0.3	50
2.5×8×4D×R0.2×50L×4F	2.5	6	4	R0.2	50
2.5×8×4D×R0.5×50L×4F	2.5	6	4	R0.5	50
3×8×3D×R0.3×50L×4F	3	8	3	R0.3	50
3×8×3D×R0.5×50L×4F	3	8	3	R0.5	50
3×8×4D×R0.3×50L×4F	3	8	4	R0.3	50
3×8×4D×R0.5×50L×4F	3	8	4	R0.5	50
4×10×4D×R0.5×50L×4F	4	10	4	R0.5	50
4×10×4D×R1.0×50L×4F	4	10	4	R1.0	50
4×10×6D×R0.5×50L×4F	4	10	6	R0.5	50
4×10×6D×R1.0×50L×4F	4	10	6	R1.0	50
5×13×6D×R0.5×50L×4F	5	13	6	R0.5	50
5×13×6D×R1.0×50L×4F	5	13	6	R1.0	50
6×15×6D×R0.5×50L×4F	6	15	6	R0.5	50
6×15×6D×R1.0×50L×4F	6	15	6	R1.0	50
8×20×8D×R0.5×60L×4F	8	20	8	R0.5	60
8×20×8D×R1.0×60L×4F	8	20	8	R1.0	60
8×20×8D×R1.5×60L×4F	8	20	8	R1.5	60
10×25×10D×R0.5×75L×4F	10	25	10	R0.5	75
10×25×10D×R1.0×75L×4F	10	25	10	R1.0	75
10×25×10D×R1.5×75L×4F	10	25	10	R1.5	75
10×25×10D×R2.0×75L×4F	10	25	10	R2.0	75
12×30×12D×R0.5×75L×4F	12	30	12	R0.5	75
12×30×12D×R1.0×75L×4F	12	30	12	R1.0	75
12×30×12D×R1.5×75L×4F	12	30	12	R1.5	75
12×30×12D×R2.0×75L×4F	12	30	12	R2.0	75
3×8×3D×R0.3×75L×4F	3	8	3	R0.3	75
3×8×3D×R0.5×75L×4F	3	8	3	R0.5	75
3×8×4D×R0.5×75L×4F	3	8	4	R0.5	75
3×8×4D×R1.0×75L×4F	3	8	4	R1.0	75
4×10×4D×R0.5×75L×4F	4	10	4	R0.5	75
4×10×4D×R1.0×75L×4F	4	10	4	R1.0	75
4×10×6D×R0.5×75L×4F	4	10	6	R0.5	75
4×10×6D×R1.0×75L×4F	4	10	6	R1.0	75
5×13×6D×R0.5×75L×4F	5	13	6	R0.5	75
5×13×6D×R1.0×75L×4F	5	13	6	R1.0	75
6×15×6D×R0.5×75L×4F	6	15	6	R0.5	75
6×15×6D×R1.0×75L×4F	6	15	6	R1.0	75
8×20×8D×R0.5×100L×4F	8	20	8	R0.5	100
8×20×8D×R1.0×100L×4F	8	20	8	R1.0	100
8×20×8D×R1.5×100L×4F	8	20	8	R1.5	100
10×25×10D×R0.5×100L×4F	10	25	10	R0.5	100
10×25×10D×R1.0×100L×4F	10	25	10	R1.0	100
10×25×10D×R1.5×100L×4F	10	25	10	R1.5	100
10×25×10D×R2.0×100L×4F	10	25	10	R2.0	100
12×30×12D×R0.5×100L×4F	12	30	12	R0.5	100
12×30×12D×R1.0×100L×4F	12	30	12	R1.0	100
12×30×12D×R1.5×100L×4F	12	30	12	R1.5	100
12×30×12D×R2.0×100L×4F	12	30	12	R2.0	100

7.Hiboo Shipping and delivery

Samples	3-7 workdays
Bulk	7-30 workdays ,it will depond on the order quantity
Samples	TNT, EMS,DHL, Fedex,UPS
Bulk	TNT, EMS,DHL, Fedex,UPS , By Common Air ,By sea

8.Why Choose Hiboo Tools

1.Several years' professional producting and exporting experience

2.Advanced RD department meet your special demands

3.High precision CNC machines,high standard and strict inspection

4.Custom demand are welcomed ,OEM and ODM Service

5.Fast delivery time and Convenient Transportations

6.More than 20000 products are available

7.For your suggestions or complaints,We will handle them Soonest

9.RFQ

1.Are you manufacturer or trading company ?

We are Professional manufacturer with own export&import license. More than 10 year exporting experience.

2.What cnc machines do you use?

More than 10 pcs ANCA ,Walter CNC grind machines ,and professional staff to make sure the good quality , with short delivery time .

3.What's your incoterm?

FOB shanghai/Ningbo, CIF , CFR ,EXW

4.Can you send products to our Forwarder in China?

Yes,with our pleasure to send goods to your China forwarder.

5.Can you do the OEM or ODM?

Yes, we can. We can laser your logo and brand on the cutter's shank , printed lable on the box.

6.Will you attend International Exhibition?

Yes, we had attended exhibitions in India, Thailand, Vietnam, Taiwan, Turkey etc. We'll plan to go more fairs.

7.Can we be your distributor ?

Yes, of course . Welcome to contact us for this matter.

8. Can you product special cutting tools according to drwaing ?

Yes We can. We will check the drwaing and reply you in 1 workday.

9. Do you Have any certificate of your factory?

Our factory pass SGS and ISO9001 Certification
